thermal panel printer with ultra big roll bucket ms-sp701
features
ultra big roll bucket diameter max 50 mm
wide range power supply dc5.5~8.5v
compact panel mounted structure
support windows/linux/android platform
over100kmprinting reliability
high printing speed max80 mm/s
interface diversification
specification
|
model |
ms-sp701 |
|
|
mechanism |
printing method |
thermal dot line |
|
dot numbers（dots/line） |
384 dots/line |
|
|
resolution （dots/mm） |
8 dot/mm |
|
|
printing speed（mm/s）max |
80 |
|
|
paper width（mm） |
58 |
|
|
printing width（mm） |
48 |
|
|
roll diameter max |
φ50mm |
|
|
paper thickness |
60～80 μm |
|
|
paper loading method |
easy loading |
|
|
auto cutting |
no |
|
|
sensor |
printer head |
thermistor |
|
paper end |
photo interrupter |
|
|
power feature |
working voltage（vp） |
5v~8.5v |
|
power consumption |
2.8a（average） |
|
|
peak current |
4.64a |
|
|
environment |
working temperature |
0～50℃ |
|
working humidity |
10～90%rh |
|
|
storage temperature |
-20～60℃ |
|
|
storage humidity |
5～95%rh |
|
|
reliability |
pulse |
100,000,000 |
|
printing length（km） |
over 100 |
|
|
property |
dimension |
76.6×73.6×54.8mm |
|
weight |
82±15g |
|
|
support |
interface |
rs-232/ttl/usb |
|
commands |
esc/pos |
|
|
driver |
windows/linux/android |
|
application
cash register; handheld terminals; measuring instruments and analyzers; mobile printers; weighing scales; medical devices; vehicle mounted recorder and more
