seiko ltpz245n+main board ms-hs700
——the smallest minitype panel printer
special feature:
1. can be flexibly embedded in a variety of instrument;
2. maximum paper roll diameter 23 mm
3. paper loading easy from front panel
4. wide voltage range for user choose
5. more compact and light structure;
specification:
|
printing performance |
printing methods |
thermal line printing |
|
line dot |
384 dots / each line |
|
|
resolution ratio |
8 dots /mm |
|
|
paper printing width |
48 mm |
|
|
printing speed |
40mm /second（max） |
|
|
paper feed length |
0.125 mm |
|
|
chars/chinese chars |
characters number |
32 / each line |
|
chinese characters number |
24 dot matrix：16，16 dot matrix：12（twice enlargement） |
|
|
ascⅱdot matrix（wⅹh dots） |
24 dot matrix storeroom：12×24，16 dot matrix storeroom：8×16 |
|
|
ascⅱsize （wⅹh mm） |
24 dot matrix storeroom：1.5×3，16 dot matrix storeroom：2×4 |
|
|
printing chars |
gbk18030 big font storeroom |
|
|
chinese dot matrix（wⅹh dots） |
24×24，16×16, 12×12； |
|
|
chinese chars size（wⅹh mm） |
24 dot matrix：3×3，16 dot matrix：4×4（twice enlargement） |
|
|
diagram/bar |
available for printing |
|
|
controlling system |
surface interface |
serial rs232 /ttl admitted baud rate：9600bps |
|
buffer |
6k bytes |
|
|
order system |
esc/p printing order， |
|
|
driver |
win2000/nt/xp serial |
|
|
power source |
working voltage |
dc 5v |
|
average current |
1a～1.5a |
|
|
peak point current |
2a～3a |
|
|
reliability |
printing life |
10 billion pulses /50 km printing length |
|
paper |
type |
common thermal paper |
|
width |
58mm |
|
|
thickness |
65±5um |
|
|
scroll diameter |
20mm |
|
|
paper change way |
convenient |
|
|
cutting method |
tear out |
|
|
physical property |
working temperature arrange ℃ |
0～55℃ |
|
storage temperature arrange℃ |
–25～70℃ |
|
|
working humidity degree（%rh） |
10～90%rh |
|
|
storage humidity（%rh） |
5～95%rh |
|
|
weight |
115g（add to paper scroll） |
|
|
net weight |
98g |
|
|
overall dimension (lⅹwⅹh mm) |
compact type (76*44*42)
|
