features:
mini mounted panel structure
easy paper loading
90°paper feeding
diameter roll: max 23mm
low driving voltage is 2.7v~5.5v
mechanism is compatible with aps-ss205
low noise
specification:
|
mechanism |
|
|
|
printing method |
thermal dot line printing |
|
|
dot structure |
384 dots/line |
|
|
dot pitch |
8 dots/mm |
|
|
printing width |
48 mm |
|
|
printing speed |
35~70mm/s |
|
|
paper width |
58 mm |
|
|
paper diameter |
23mm(max) |
|
|
paper thickness |
60-100 um |
|
|
paper loading |
easy paper loading |
|
|
character size |
12*24, 32 characters/line |
|
|
24*24, 16 characters/line |
||
|
8*16, 48 characters/line |
||
|
16*16, 24 characters/line |
||
|
power supply |
printer head |
4.2v~8.5v,1.9a(5v) (average) |
|
dynamo |
4.2v~8.5v,0.5a(5v) (max) |
|
|
logic voltage |
2.7v~5.5v,0.05a(5v) (max) |
|
|
dimensions (w*d*h) |
79.15*38.17*44.19 mm (depth:45mm) |
|
|
weight |
32 g |
|
|
electric life: wear life |
more than 110,000,000 pulses more than50 km |
|
|
ambient condition |
operating temperature |
0 ℃~50℃ |
|
operating humidity |
20~85% rh |
|
|
storage temperature |
-25℃~70℃ |
|
|
storage humidity |
10~90% rh |
|
|
sensor |
tph temperature |
thermistor |
|
paper end detection |
photo interrupter |
|
|
controlling board: |
|
|
interface |
rs-232/ttl/usb |
|
driver power |
dc 8.5v/2.5a |
|
dimension |
30*50 |
|
weight |
2.3 g |
application:
handheld mobile device; ecr/financial pos printer; weighing scale; fire controller printer; medical device; measuring instrument printer; cash register printer; vehicle-mounted recorder; taxi meter printer and more
