ms-530i
bidirectional logistic printing, reaching in 150mm/s
good reliability , reaching in 50km automatic cutting, above 100 million times
ms-530i pcb ( printing control board) is 80mm printing module, which is specially designed for m-t532 printing head. its has compact structure and high quality. its application fields ; kiosk, self-service inquiry machine, automatic call distributor, atm, parking lot ticket printing, lottery printer, daily record printing, self-service telephone bill printing, invoice printer and so on.
the greatest feature is “all-in-one” concept, board and printing head integrates so completely that provides more space for user. and user can take advantage of the space for structure design.
|
type |
ms-530i |
|
|
printing |
method |
dot line thermal printing |
|
dot number (dot/line) |
576 |
|
|
resolution dot/line) |
8 |
|
|
paper width (mm) |
80 |
|
|
printing width （mm） |
72 |
|
|
printing speed （mm/s） |
150 |
|
|
paper feed direction |
automatic feeding by sensor |
|
|
check method |
printing head temperature |
heat sensor |
|
paper out check |
photoelectrical sensor |
|
|
pull rod check |
mechanical switch |
|
|
operation voltage |
working voltage （vp） |
24v±10% |
|
power consumption |
average 1.75a ( maximum dot |
|
|
printing life |
pulse number |
10 billion |
|
printing length(km) |
100 |
|
|
current flow (a) |
6.0 max |
|
|
operation temperature (℃) |
-10 to50 |
|
|
dimension (w*d*h mm) |
126.9*91.9*57.5 |
|
|
weight(g) |
about 550 |
|
