ms-80rw daily recording printer:

　　it is 80mm(3’inches) thermal printer with automatic paper winder. this new design can recycle receipt without any manual work!

　　feature:

　　1. printing and retracting simultaneously

　　printer and stacker works at the same time. this can save manual work time and do more convenient for user to keep receipt.

　　2. low voltage for power supply

　　the logic driving voltage of head is 3.0~5.25 v; heating voltage is 4.2~8.5v.this design can meet 4~6 ni-mh batteries or 2 li-ion batteries.

　　3. compact and lighting structure

　　the compact outside dimension is suitable for building in any device or place.

　　4. high resolution printer

　　high density printer head, as 8 dots/mm , is more clear than dot-matrix effect.

　　5. easy loading paper roll

　　platen-free design meet easily loading paper requirement.

　　6. low noise

　　this does help for high request environment of noise.

　　specification：ms-sz501 daily recording printer

　　model :ms-sz501;　stacker :star original;　structure size :240(l)x141(w)x102(h)(mm)

　　input voltage :dc 10.8v-13.2v;　　interface :rs-232/usb;　　printing method: thermal dot line

　　dots/line: 576 dots/line;　　density :8 dots/mm;　　printing width :72 mm;　　paper width :80 mm

　　roll diameter :90 mm;　　printing speed :80 mm/s;　　feeding pitch: 0.0625 mm;　　heating detector of head :thermistor

　　paper detector :photoelectric sensor;　　reliability :50 km

　　working temperature(℃) :0～50;　　working humidity(rh) :20%～85%;　　

        storage temperature(℃): -20～60;　　storage humidity(rh) :5%～90%

　　application:

　　industrial controlling system, agriculture batch feeder, commercial daily recorder, pos data recorder, information collector, bill payment machine, hotel self-service terminal and more

　　matters and attentions

　　1. the tph and photoelectric sensor are belongs to electrostatic sensitive devices, on printer working user should take static-free actions.

　　2. when user loads platen on head, this component should keep clear or will influence printing effect.

　　3. user should keep thermal head in clear and dry environment.

　　4. please load platen in right position of gear

　　5. do not connect fpc with pin on board by hand directly. moreover, there is warning for pull off fpc out of pin on power.

　　6. do not bending fpc in any angle or will damage it.

　　7. when paper jam happens user should pick up platen for first.

　　8. do not use damp paper or will damage printer.

　　9. printer can not work on lacking of paper.

　　10. pinter can not work on high temperature over75 ℃。

　　11. paper quality will influence printer effect and life.
