3’’ thermal kiosk printer ms-2320
features:
citizen lt2320 printer head
separated installation structure
auto cutter: full/partial cutting
high speed max150 mm/s
multiple languages printing
error status speaker alarm
thick paper up to0.15mm
specifications:
|
mechanism |
|
|
|
printing method |
thermal line dot printing |
|
|
dots/line |
576 dots/line |
|
|
dot density |
8 dots/mm |
|
|
paper width: |
80 mm |
|
|
paper thickness |
60-105 um (standard); 110~150um (a type) |
|
|
printing width |
72mm |
|
|
printing speed |
max150mm/s |
|
|
paper feeding pitch |
0.125mm |
|
|
cutter |
full/partial cutting by optional |
|
|
sensor |
head temperature: thermistor |
|
|
paper presence: photo interrupter |
||
|
head-up: photo sensor |
||
|
voltage range
|
vh: dc21.6-26.4v |
|
|
vdd: dc4.75-5.25v |
||
|
current consumption
|
head: approx5.2a |
|
|
motor: approx0.41a |
||
|
reliability |
more than50km |
|
|
ambient environment |
temperature |
working: 0~45℃ |
|
storage: -20~60℃ |
||
|
humidity |
working: 35~85%rh |
|
|
storage: 10~90%rh |
||
|
dimension |
108*58*35mm |
|
|
weight |
approx279g |
|
|
controlling board |
|
|
|
interfaces |
paralle/usb/rs-232 |
|
|
power supply |
dc 24v/2.5a |
|
|
flash memmory |
128 k |
|
|
sram |
20 k |
|
|
supporting device |
automatic cutter, paper sensor, head-up sensor, lf switch, error led, paper our led |
|
|
dimension（l*w*h） |
115*102*24 |
|
|
|
|
|
|
weight |
2.1 g |
|
application:
kiosk; coupon machine, self-service terminals; parking system, lottery machine; industrial receipt printer, information inquiry system, gas station self-service ticket distributor and more
