features:
printer mechanism epson m-t183
panel led for various printer status indicators
high speed70 mm/s
built-in control board
bucket for big diameter paper roll
low noise
specifications:
|
mechanism |
ms-601 |
|
printing method |
thermal dot line printing |
|
dots number |
384 dots/line |
|
printing density |
8 dots/line |
|
printing speed |
max70 mm/s |
|
printing width |
48 mm |
|
paper width |
57.5±0.5 mm |
|
roll diameter |
max46 mm |
|
working voltage |
dc 4.2~8.5 v |
|
head sensor |
thermistor |
|
paper sensor |
photo interrupter |
|
reliability |
mechanism life: over50 km; pulse numbers: 10,000,000,000 times |
|
working environment |
temperature:0~50℃ humidity: 20~85% rh |
|
control board |
|
|
interface |
ttl/rs-232/usb |
|
command set |
esc/pos |
|
firmware location |
flash memory |
|
buffer |
4 k bytes |
|
supporting devices |
paper end sensor, paper near end sensor |
|
total weight |
approx 63 g |
|
panel dimension |
88(l)*76(w)*42(h) |
|
accessories |
cable |
applications
panel printer, medical printer, self-service terminal, vehicle-mounted recorder, meters and measurement device，gas pumps and more
