features:

ultra fast printing speed

a4 paper width

interfaces diversification

excellent software compatibility

flat-bed paper feeding method

outstanding auto cutter

unique auto separating sheets of paper function

specification:

printing system: serial matrix

printing speed

printing method: bidirectional/single-track logic searching

pins: 24

pins span: 300,000,000 dots/pin

line pitch: 1/6 inch, 1/8 inch, n/60 inch, n/180 inch, n/360 inch

english script: roman, gothic letter

chinese script: song typeface

character set: 96 western letters ascii

international set, 16 countries

32 ibm sets

chinese gb 18030-2000 24*24

96 semiangles ascii

paper width: 4.9-10.1 inch (single paper)

5.5-10 inch (chaining paper)

paper length: 3.3-14.3 inch (single paper)

min5.5 inch (chaining paper)

paper thickness

0.07mm（single paper）-0.5mm (multi-ply paper)

copy ability: 1+6 copy

command: esc/p-k+ ar

oki+great wall5360

paper feeding method: flat-bed feeding

feeding speed: 5 inches/s

buffer: 128k/bytes

interface: ieee-1284 (standard type)

ribbon: cs24

ribbon life: 450,000 characters

mtbf: above 10000 hours

size: 363(l)*244(w)*205(h) mm

weight:5.9 kg

power supply: 220v (allowing range 187v-253v) 50/60hz

consumption: standby 10w

printing 55w

working environment: temperature 5~35

humidity 30%~80%

accessories: rs-232 interface converter

usb interface converter

cable

user manual

application:

tax invoice; courier receipt; lading bill; insurance paper and more
