　　name： ms-tv80

　　application：atm equipments; multiple vendor; parking management system; gas station; cash coupon printer and more

　　special feature:

　　· 1. more serviceable and convenient structure design;

　　· 2. brilliant paper container providing enough space;

　　· 3. excellent automatic cutter saves manual work;

　　· 4. unique photoelectric sensor detects "paper out" for users

　　· 5. special paper delivery mouth prevents from paper jam

　　specification：

　　printing method ：thermal line printing

　　printing speed ：150mm/sec

　　printing direction ：bi-directional

　　dot density： 576 dots/line

　　printing width ：54mm/72mm

　　sensor ：printer head, thermistor; paper, photoelectric sensor; platen open, photoelectric sensor

　　power supply ：vh dc21.6-26.4v; vdd dc4.75-5.25v

　　current： printer head(vh=5v) max5.2a

　　power consumption： motor(vh=5v) max0.41a

　　paper： 58±0.5mm; diameter：max 150mm; thickness：0.06-0.10mm/0.11-0.15mm

　　reliability ：

　　printing：50km; printer head：50,000,000; auto cutter：1million cuttings

　　operating environment：

　　operation: 0-45℃; storage :-20-60℃

　　dimension ：108(l)×58(w)×20(h)mm
