gps printer ms-hs700 :
|
printing performance |
printing methods |
thermal dot matrix printing |
|
line dot |
384dots / each line |
|
|
resolution ratio |
8dots /mm |
|
|
paper printing width |
48mm |
|
|
printing speed |
40mm /second（max） |
|
|
paper feed length |
0.125mm |
|
|
chars/chinese chars |
characters number |
32/ each line |
|
chinese characters number |
24dot matrix：16，16dot matrix：12（twice enlargement） |
|
|
ascⅱdot matrix（wⅹh dots） |
24dot matrix storeroom：12×24，16 dot matrix storeroom：8×16 |
|
|
ascⅱsize （wⅹh mm） |
24 dot matrix storeroom：1.5×3，16dot matrix storeroom：2×4 |
|
|
printing chars |
gbk18030 big font storeroom |
|
|
chinese dot matrix（wⅹh dots） |
24×24，16×16, 12×12； |
|
|
chinese chars size（wⅹh mm） |
24dot matrix：3×3，16 dot matrix：4×4（twice enlargement） |
|
|
diagram/bar |
available for printing |
|
|
controlling system |
surface interface |
serial rs232 /ttladmitted baud rate：9600bps |
|
buffer |
6kbytes |
|
|
order system |
esc/pprinting order， |
|
|
driver |
win2000/nt/xpserial |
|
|
power source |
working voltage |
dc 5v |
|
average current |
1a～1.5a |
|
|
peak point current |
2a～3a |
|
|
reliability |
printing life |
10 billion pulses /50 kmprinting length |
|
paper |
type |
common thermal paper |
|
width |
58mm |
|
|
thickness |
65±5um |
|
|
scroll diameter |
20mm |
|
|
paper change way |
convenient |
|
|
cutting method |
tear out |
|
|
physical property |
working temperature arrange ℃ |
0～55℃ |
|
storage temperature arrange℃ |
–25～70℃ |
|
|
working humidity degree（%rh） |
10～90%rh |
|
|
storage humidity（%rh） |
5～95%rh |
|
|
weight |
115g（add to paper scroll） |
|
|
net weight |
98g |
|
|
overall dimension (lⅹwⅹh mm) |
compact type |
